1000mm 3 In One Welding Machine Hydraulic H Beam Flange Straightening Machine

Name: 1000mm 3 In One Welding Machine Hydraulic H Beam Flange Straightening Machine
Brand: YAOQIANG
Price: 1 USD

Brand Name : YAOQIANG

Model Number : YQPJ

Certification : CE,ISO

Place of Origin : JIANGSU,CHINA

MOQ : 1 set

Price : US $42,000-55,000/ Piece

Payment Terms : L/C, T/T, Western Union

Supply Ability : 10pcs/month

Delivery Time : 30days

Packaging Details : standard package

Automatic centering method : Hydraulic motor

Electric control box : Well-known brand

Welding method : Single arc single wire or single arc double wire

Straightening method : Hydraulic straightening

Speed regulation : AC frequency conversion speed regulation

Main drive mode : Motor reducer

Contact Now

H Beam Flange Web Automatic Centering Assembly Spot Welding And Hydraulic Straightening Machine

Supply matching:
Frame;
Console;
Pre assembled mechanism;
Feed roller table;
Delivery roller table;
2 sets of welding machine;
Hydraulic station;
Mushroom shaped deformation correcting mechanism for beam;
Welding console -2 sets for wire feed mechanism;
Wire box -2 parts;
Hydraulic hose;
Flux cycle system ----2 set;
Work platform and ladder;

The supply does not include:
1. foundation;
2. connect to the power and air source of the equipment;
3. equipment grounding;

4. welding wire or flux etc

Type	Web height	Thickness of the web	Welding speed	Flange width	Thickness of flange	Overall power
YQPJ1000	1000mm	6-16 mm	0.35-3 m/min	200-800 mm	6-20 mm	13.4 kw
YQPJ1200	1200mm
YQPJ1500	1500mm

This is a H-shaped steel assembly, straightening and welding integrated machine that we have applied for a patent and obtained CE certification. At present, it has been widely praised at home and abroad, and this three-in-one machine 3in1 welding line has been exported to many countries.

The machine mainly includes:
Automatic spot welding assembly machine
Hydraulic straightening machine (can be modified into a small straightening machine for independent use according to customer requirements)
Submerged arc welding single arc double wire or single arc single wire automatic welding machine
